Musktool-DNA30 PCR 96 Well DNA Amplification Thermal Cycler Gradient PCR Machine

  • Main Features :
  • Serial No. : monica0677
Contact Us For QuotationEmail:  464560351@qq.comWhatsapp&Wechat:+8618620373879

Musktool-DNA30 PCR 96 Well DNA Amplification Thermal Cycler Gradient PCR Machine

Features

1. Small footprint, compact design
2. 6 high precise peltiers
3. Good temperature uniformity reduce edge effect
4. 1024x768 pixel,8 -inch color touch screen Automatically power failure recovery
5. Gradient range 42°C
6. Peltier based technology, max heating up rate 6'C /sec

Specifications for WT-96 (96 wells gradient)

ModelPC-96Max.Heating Rate5℃/S
VoltageAC100~240V
50/60Hz		Max.Cooling Rate4.5℃/S
Temperature
Control ways		Block or TubeGradient Set SpanMax.42℃
Block Temperature
Range		0~105℃Gradient
Temperature
Accuracy		±0.3℃
Timer1s~59min59sec/
Infinite
Temperature
display accuracy		0.1℃
Block Temperature
Accuracy		±0.2℃Heating Lid
Temperature range		30℃~110℃
Block Temperature
Uniformity		±0.25℃Automatically
Heating Lid		Shut off automatically when
sample lower than 30℃ or
program over
Heating Up Rate
(average)		4℃Timer Increasing/
Decreasing		-599~599S for Long PCR
Cooling down Rate
(average)		3℃Temperature
Increasing/
Decreasing		-9.9~9.9℃ for Touchdown
PCR
Gradient
temperature range		30-105℃Max.Power600W
Programs stored10000+Real-time operation
status		Image-text
displayed
Max.Cycles99Interface PortUSB2.0
Max.Steps30Dimension(W×D×H)200x300x170
(mm)
Program Pause
Function		YesWeight4.5kg
16℃ Temperature
Holding Function		InfiniteCapacity96x0.2ml(PCR plate without/semi skirt), 12×8x0.2ml strips, 8x12x0.2ml strips, 0.2mltubes(height 20~23mm)

Specifications for WT-32 (32 wells)


Model
PC-32		Cooling Down Rate(Max.)
4℃ /S

Capacity		32x0.2ml(microtubes), 4x8x 0.2ml (tubes strips)Gradient Temperature Range
30 ～ 100℃
Block Temperature Range
4~100℃
Gradient Set Span
Max. 30℃
Numbers of Peltier
2		Gradient Temperature Accuracy
±0.3℃
Temperature Display Accuracy
0.1℃		Gradient Temperature Uniformity
±0.3℃
Block Temperature Uniformity
≤ ±0.25℃		Temperature Control ways
Block or Tube
Block Temperature Accuracy
±0.2℃		Timer Increasing / Decreasing
- 599~599 S for Long PCR

Timer		1s~59min59sec/
0 Infinite Duration
Temperature Increasing / Decreasing-9.9~9.9℃ for Touchdown PCR
Heating Lid Temperature range
30℃ ~105℃
LCD display
Touch screen display
Heating Up Rate(Max.)
5℃ /s
Programs stored
200

Max. Cycles
99		Real-time operation status
Image-text displayed

Max. Steps
30
Size (W×D×H)
243×172×145（mm）
Power failure recovery
Yes
Net weight
2.3kg

Pause function
Yes
Max. Power
225W
16℃ Temperature Holding Function
Infinite duration
Voltage Range
AC110V-220V 50-60Hz
