Musktool-KS-C2W color discrimination tracking photoelectric

Musktool-KS-C2W color discrimination tracking photoelectric

2024-07-22 17:38:19

Musktool-KS-C2W color discrimination tracking photoelectric

Main Features :
Serial No. : monica0455

Specification

Contact Us For Quotation

Email: 464560351@qq.com

Whatsapp&Wechat:+8618620373879

Musktool-KS-C2W color discrimination tracking photoelectric

Introduction

Matching GK-4/GK61/GK62/GK71/GK72 and other photoelectric correction controller used, tracking film, paper and other materials, high sensitivity, accuracy. Longyou products are specially used for color discrimination and correction

Characteristic

The light is green

Optical Design of Coaxial Reflectance

The spot of light is and the detection is accurate

Design of Short Circuit Protection for Output Circuit

Technology features

illuminant	Green light 525 nm
Detection Methods	Coaxial reflector
Detection distance	12mm
supply voltage	12-30Vdc
Current consumption	40 mA Below
answering time	1 mS Below
export	Double output of bright and dark, short circuit protection
Action indicator	Brightness indicator LED, red
External Light	Light bulb 10000 Lux, Sunlight 100000 Lux
end-use temperature	Movement :-20℃-70℃, save :-25℃-80
wire	UL2464 fire insulation four-core cable (brown, black, white, blue)
hull	Grey, PBT 30% fiberglass

Lable: Musktool-KS-C2W color discrimination tracking photoelectric
